Now discontinued – the EZGO RXV is no longer manufactured, but it remains widely used and we fully support existing owners with servicing, repairs and parts.
The EZGO RXV is one of the most common golf buggies on UK courses and estates. Whether yours is a 48-volt AC electric model or the 13.5 hp petrol version, a little regular care keeps it safe, reliable and running sweetly for years. This guide covers the routine maintenance an RXV owner can do between professional services.
The RXV earned its reputation on an efficient AC drivetrain and its patented AutoBrake system, which applies the parking brake automatically and uses regenerative braking to put charge back into the batteries. Those features are brilliant in use, but they also mean a few RXV-specific checks are worth knowing about.
If anything here is beyond what you want to take on yourself, we service and repair the RXV – and every other make and model – just get in touch.
| Power options | 48V AC electric, or 13.5 hp petrol |
|---|---|
| Drivetrain | AC electric drivetrain with regenerative braking |
| Braking | Patented AutoBrake – motor brake + automatic park brake |
| Hill performance | Maintains ~97% of speed on steep grades (electric) |
| Seating | 2-seat standard |
| Typical battery | 6× 8V lead-acid (48V), or lithium upgrade |
How you look after the batteries makes the biggest difference to an electric buggy's life. If you have a lithium (LiFePO4) pack it's virtually maintenance-free – charge when convenient, partial charges are fine. For lead-acid batteries: charge after every use, avoid deep discharges, keep the water above the plates (top up with distilled water after charging), keep the tops clean, and always charge in a well-ventilated space away from sparks or flames.
Check pressures regularly and take care inflating – these small tyres fill fast and over-inflate easily. Keep pressures even across the buggy for stable handling.
Many EZGO RXV owners upgrade from lead-acid to a lithium pack for lighter weight, faster charging and near zero maintenance. We carry out lithium conversions – see our Lithium Battery Upgrades page.
| Symptom | Possible cause | What to do |
|---|---|---|
| Vehicle will not move | Key off or no direction selected | Turn key on and select a direction. |
| Batteries discharged | Charge the batteries fully. | |
| Corroded or loose battery connections | Clean and tighten the connections; protect terminals. | |
| Solenoid, key switch or controller fault | Have a technician test and replace the faulty component. | |
| Speed erratic / no reduced speed in reverse | Controller (ESC) fault | Technician test and replace components as indicated. |
Need parts or maintenance help for your EZGO RXV – or any other make and model? We can help. Contact us and tell us what you need.
